Central South University choose SERVOTEST to supply the worlds first 4 x 6 DOF Earthquake Simulation System.
EQUIPMENT SPECIFICATION SUMMARY
- Number of tables - 4
- Degrees of freedom/Table - 6
- Table size - 4M x 4M
- Specimen weight / Table - 30 tonnes
- Acceleration X and Y - 0.8'g'
- Acceleration Z - 1.6 'g'
- Hydraulic Power - 1.3 Mega Watts
The four table system offers complete freedom of static position for testing complex bridge models. The maximum positions are shown below.
